Wind   turbine input

Rated input   Power

20kW

Max input   Power

30kW

Rated input   voltage

400Vac

MPPT   voltage range

100Vac~450Vac

Rated input   current

30A

Max input   current

45A

cutting   speed

60RPM（factory   default，0-1499RPM settable）

Power   tracking

30 points   set power curve

Speed limit   control

Electromagnetic   speed limit

Manual   brake

keep   pressing the button 5s unload completely,and then recover by pressing it for   another 5s

Tune the switch   on the panel to"BRAKE position",three-phase AC short cricuit,turn   to "RUN" position to run.

Brake by   overcurrent

45A（factory   default,0-54A settable）it dumps load   completely when overcurrent,and will recover after 10mins automatically

Brake by   over rotational speed(optional)

300RPM（factory   default，0~1499RPM settable）unload completely when   reached the set rotational speed ,and recover automatically after 10mins

Brake by   over wind speed(optional)

18m/s（0~30m/settable），it dumps   load completely when reached the set wind speed ,and recover automatically   after 10mins

AC output

Grid type

Three phase

Rated   output power

20kW

Max output power

22kW

Rated   output voltage

400Vac

Grid   voltage range

85%~110% of   rated grid voltage

Rated grid   frequency

50Hz/60Hz   adaptive

work   frequency range

49Hz~51Hz/59Hz~61Hz

Rated   output current

30.4A

Rated power   factor

＞0.98

Thdi

＜5%（at rated   power）

DC   component

＜0.5%

soft start

Yes

Restoring   grid-connected functionalit

Yes

Auto on/off

Yes

Protection   functions

grid   overvoltage/undervoltage protection

Yes

grid over   frequency/under frequency protection

Yes

output   short circuite protection

Yes

Grid power   failure protection

Yes

Anti-islanding   protection

Yes

over   temperature protection

Yes

Lightning   protection

Yes

Residual   current protection

Yes

General   Parameters

Display   mode

LED

Display   informational

dump load 、grid state、wind   generator state、faults

Monitoring   mode(optional)

RS485/GPRS

Monitoring   contents

Telemetry:   wind turbine speed, grid voltage, output power, power generation;

Remote   signal: wind turbine status, wind power grid-connected inverter over-current   alarm, over-voltage alarm, over-temperature alarm, fault alarm, etc.;

Remote control: modify the parameters of the wind power grid-connected   inverter and control the braking of the wind turbine

Efficiency

＞95%

Ambient   temperature

-20℃～+40℃

Humidity

0%~90%，no   condensing

Vibration   resistance

Can   withstand sine wave vibration with a frequency of 10Hz~50Hz and an amplitude   of 0.35mm

Noise

≤65dB

Cooling   mode

natrual   cooling

Cover   protection class

IP65（dump load   IP54）
