Product details



Function ItemParameter
Operation PanelSilicon Rubber
LanguageChinese & English & Others
Digital Input5
Relay Output6
Analogue Input3
AC System1P2W/2P3W/3P3W/3P4W
Alternator Voltage(15~360)V(ph-N)
Alternator Frequency50/60Hz
kW/Amp Detecting & Display*
Programmable InterfaceUSB
RTC & Event Log*
Scheduled Start Genset*
DC SupplyDC(8~35)V
Case Dimensions(mm)209*166*44
Panel Cutout(mm)186*141
Operating Temp.(-25~+70)℃

Key Benefits
*Real-time clock provides accurate event logging
*Multiple date and time scheduler
*Set maintenance periods can be configured to maintain optimum engine performance
*Ethernet communications, provides advanced remote monitoring at low cost
*Modules can be integrated into building management systems (BMS)
*Increased input and output expansion capability
*Licence-free PC software
*IP65 rating (with supplied gasket) offers increased resistance to water ingress
*PLC editor allows user configurable functions to meet specific application requirements
