Product details




OVERVIEW


ModelOW-5KWH
Rated Voltage220V/380V or customized
Wind Turbine Diameters4m
Blade Height5m
Rated Power5kW
Power RegulationMPPT
Rated RPM100 RPM
Start-up Wind Speed2.3m/s
Rated Wind Speed11m/s
 Maximum Wind Speed53m/s
Braking SystemElectromagnetic
Electronic Unloading10kw braking resistor box
Hydraulic BrakeActive braking, power failure braking
Controller UnitPLC
HMIHMI
AlternatorThree-phase ironless permanent magnet synchronous
Design ClassIEC Class Ⅲ
Insulation ClassH
Blade MaterialsAlloy
Blade Qty3/4/5
Noise62FB
Noise Level<65dBA
Temperature‐20°C~50°C
AltitudeBelow 2000m
Protection ClassIP54
Service Time20  year
Tower TypeIndependent pole/tower
CertificateCE
*The specifications above are just for reference. Contact us for more customized solutions!!
