OWELL 100KW horizontal axis electronically controlled wind turbine power generation

Product Features

1. Low Torque when start-up. high power generating efficiency

2. Tight fit design to wind wheel. 3 blades are assembled as 120° accurately so that wind wheel runs stably.

3. Tight fit design between wheel grooves and blades, which enhances the safety and stability of whole generator

4. With intelligent microprocessor control to maximum power track, adjusts voltage and electric current effectively

Product details

Product Description

●Wind wheel: 3 blades wheel, Laminar flow type, high lift-drag ratio, good performance. Reinforced glass fiber blades, strong toughness and perfect dynamic nature.

●Generator and swivel are designed in a complete body, a close compact structure which enhances toughness, reduce weight of the generator set, and thus make it rotate more easily and safely.

●Hub: It adopts integrated flange hub design, internal groove taper design, perfectly seamless matching with spindle, safe and reliable use.

100KW wind turbine parameters

Model	OWELL-HR100KW
Rate Power	100KW
Max.Power	110KW
Rate Voltage	≥380V
Wheel Diameter	24m
Start-up Wind Speed	3m/s
Rated Wind Speed	11m/s
Extreme Wind Speed	50m/s
Blade Quantity	3 pcs
Blade Materials	FRP
Generator housing Materials	Qualitative Carbon Steel
Export Packing	Wooden Box
Generator Type	3 phase AC permanent magnet alternator
Alnico Magnet	NdFeB
Brake Mode	Electromagnetic
Lubricating	self-lubricating
Wind Adjustment	Electronitically controlled yaw
Work Temperature	-40℃-80℃
